1. How to Zero the Yokogawa Vortex Flow Meter
The core steps for zeroing the Yokogawa Vortex Flow Meter have been sorted out and must be strictly followed during operation. 1. Before operation, prepare to switch the flowmeter to the "normal measurement screen" state, ensuring that the current interface can be modified with parameters.
2. During the password verification stage, short press the ENT key in the measurement screen to activate the input interface, and then enter the preset reset password XX (specific password is subject to actual settings) through the panel keys. After completion, press the ENT key to confirm.
3. Menu navigation The operating system now enters the "cumulative quantity selection" secondary menu, and continue to press the ENT key to enter the editing mode. At this point, the visible menu options start flashing. Use the NEXT key to cycle through the options until the cursor stays at the "Reset" function item. 4. Perform the reset action. After selecting the reset function, press the ENT key again to terminate the flashing state and lock the operation instruction. At this point, the system has recorded the reset parameter changes. 5. Exit the setting mode. Finally, press the ESC key continuously to exit the menu step by step until you return to the normal fiber sales work interface. Observe whether the display screen value returns to zero. If it does not take effect, repeat the operation process to verify the accuracy of the password.
2. How to change the unit of ton for the Yokogawa Wokou flowmeter
Enter the flowmeter settings menu.
.1、 Find the single town ridge location option and select the function to change the unit.
2、 In the list of a
3、 Save the changes to Shifeng and exit the settings menu.
3. Parameter setting after replacing the sensor of Yokogawa electromagnetic flowmeter
The parameter setting after replacing the sensor of Yokogawa electromagnetic flowmeter dispersion meter needs to focus on calibrating the sensor coefficient, ensuring that the measurement aperture matches, and adjusting the auxiliary functional parameters.
. 1. Core parameter setting and measurement diameter: It must be completely consistent with the actual diameter on site. If the diameter parameter is incorrect, it will cause deviation in flow calculation. Sensor coefficient value matching: This value needs to be strictly matched with the original parameters of the converter or the labeled value on the sensor nameplate, usually represented by the "K coefficient", which directly affects the signal conversion accuracy. two Auxiliary parameter adjustment, flow unit and display digits: Set the unit according to the working condition requirements (such as excavation failure m ³/h, L/min), and define the integer and decimal digits for flow display. Cumulative flow unit: Usually cubic meters or liters are selected as the cumulative value unit, which needs to be consistent with other instrument units in the system. Measurement of damping time: Used for smoothing flow fluctuations, the default value is generally 2-5 seconds. If the working fluid fluctuates greatly, it can be appropriately extended. Small signal cut-off point: It is recommended to set it to 1% -5% of the full range to avoid false counting caused by pipeline empty pipes or small flows. three After completing the parameter set
