1. Overview of GD87

GD87 is a code specifically used for power pipelines, mainly applied to power pipeline accessories such as water flow indicators or single tube water flow sight glasses. This accessory is a key tool for monitoring the flow of media in pipelines, widely used in industrial production environments such as power, petroleum, chemical, synthetic fiber, medicine, and food. It can observe the flow status of media such as liquids, gases, and steam in real time, which is crucial for maintaining the normal operation of production processes. The GD87 series includes two models, GD87-0912 and GD87-2000. The GD87-0912 model is produced by the Subat brand and is a type of impeller flowmeter with a wide measurement range from 0.2 to 250 cubic meters per hour, with an accuracy level of Riddle Core 1. Its nominal diameter range is between DN6 and DN400 millimeters, suitable for water, oil, gas, as well as acidic or toxic liquids or gases. The working pressure can reach 0.6/1.0/1.6/2.5/4.0 megapascals, and the temperature adaptation range is -10 to 195 degrees Celsius. GD87-2000 is slightly different. It is also a Subat brand impeller flowmeter, with a measurement range reduced to 0.2 to 90 cubic meters per hour and a nominal diameter of DN6 to DN100 millimeters. Other parameters such as working pressure and temperature adaptability are consistent with GD87-0912, and it is also suitable for monitoring multiple media. These products are made of carbon steel or stainless steel materials, ensuring corrosion resistance and strength, and are an indispensable component of power pipeline systems.

2. Selection of saturated steam flowmeter

Model and marking instructions: LUGB □□□□□□ Stress type vortex f

low sensor - ② ③ ④ - ⑤ ⑥ Serial number connection method: 1 Flange connection type 2 Flange card type tested medium: 1 Liquid 2 Gas (including steam) sensor nominal diameter: DN010-10 mm (non-standard) DN012-12.5 mm (non-standard) DN015-15 mm (non-standard) DN020-20 mm (non-standard) DN02-25 mm DN03-32 mm (non-standard) DN04–40 mmDN05–50 mmDN06–65 mmDN08–80 mmDN10–100 mmDN12–125 mmDN15–150 mmDN20–200 mmDN25–250 mmDN30–300 mmDN35–350 mmDN40–400 mmDN45–450 mmDN50–500 mm Unmarked pulse output standard flow range K pulse output extended flow range B explosion-proof M current output DC4-20mA local display 24V power supply condition various parameters XM local display 24V power supply three wire current output BM explosion-proof, current output DC4-20mA Determination and installation design of instrument caliber: 5 Instruments can be installed horizontally, vertically, or obliquely on pipelines. When measuring gases, instruments can be installed in vertical pipelines with no restrictions on gas flow direction. But if the pipeline contains a small amount of liquid, in order to prevent liquid from entering the instrument measuring tube, the airflow should flow from bottom to top. When measuring liquid, in order to ensure that the tube is filled with liquid carefully, when installing instruments in vertical or inclined pipelines, the direction of liquid flow should be from bottom to top. If the pipeline contains a small amount of gas, in order to prevent gas from entering the instrument measuring tube, the instrument should be installed at a lower part of the pipeline. When measuring high and low temperature media, attention should be paid to insulation measures. The high temperature inside the converter (inside the header housin
